Power supply: switched-mode; modular; 150W; 12VDC; 199x99x30mm
Kordarv:
1.0
Minimum quantity:
1.0
Tootekood:
RSP-150-12
Tootja: MEAN WELL
Tootja tootekood: RSP-150-12
Product downloads
- pVersion=0046&contRep=ZT&docId=005056AB752F1ED881B4FF624CF4EA18&compId=RSP-150-SPEC.PDF?ci_sign=f9dbd44498f19d3a267767b0ea5e9fcc3ef4effd
- pVersion=0046&contRep=ZT&docId=005056AB752F1EE69AF1DDED075F4FA8&compId=INB-MN-ENCLOSED-EN.pdf?ci_sign=8e403b3848ad88af3c834f5c23e01f888bbf668c
- pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA390A2BDE3BA60C7&compId=Mean_Well_Industrial-Catalog.pdf?ci_sign=e5a3bf0d98e6bb6b792c315b1e2cf501830c330c
Spetsifikatsioon tootele Power supply: switched-mode; modular; 150W; 12VDC; 199x99x30mm
| Output current | 12.5A |
| Supply voltage | 85...264V AC, 120...370V DC |
| Power | 150W |
| Operating temperature | -30...70°C |
| Protection | overheating, anti-overload, anti-overvoltage, short circuit protection |
| Type of power supply | switched-mode |
| Series | RSP-150 |
| Body dimensions | 199x99x30mm |
| Output voltage | 12V DC |
| Additional functions | active PFC |
| Efficiency | 90% |
| Number of outputs | 1 |
| Electrical connection | terminal block |
| Kind of power supply | modular |
| Kind of case | 215A |
