Power supply: laboratory; Channels: 3; 0÷35VDC; 0÷4A; 0÷35VDC; 0÷4A
Kordarv:
1.0
Minimum quantity:
1.0
Tootekood:
EX354RT
Tootja: AIM-TTI
Tootja tootekood: EX354RT
Product downloads
- pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABC2AD97901E80D6&compId=MEASURING.txt?ci_sign=d0ccb06ee923cc677e69012bfb5fb7bd92f37df8
- pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3ABEB72103D4F21DC&compId=INB-ZAS-LAB-EN.pdf?ci_sign=db94e243c38f5821daa6230d2999c491a12c8e1a
- pVersion=0046&contRep=ZT&docId=E1C04BCB477BF0F1A6F5005056AB5A8F&compId=elr-exr-series.pdf?ci_sign=0a5f45db548e8b8dc8ec4e64c96e653e6229e139
Spetsifikatsioon tootele Power supply: laboratory; Channels: 3; 0÷35VDC; 0÷4A; 0÷35VDC; 0÷4A
| Output current | 0...4A |
| Supply voltage | 100...240V AC |
| Number of channels | 3 |
| Protection | against reverse polarity, short circuit protection |
| Type of power supply | laboratory |
| Dimensions | 260x160x320mm |
| Output voltage | 0...35V DC |
| Output voltage 3 | 1.5...5V DC |
| Output current 2 | 0...4A |
| Output voltage 2 | 0...35V DC |
| Output current 3 | 5A |
| Kind of power supply | multi-channel, switched-mode |
| Measuring instrument features | coarse and fine voltage adjustment, constant voltage or constant current operation, simultaneous voltage and current readout, voltage and current stepless adjustment |
| Output voltage resolution | 10mV |
| Output current resolution | 1mA |
| Voltage load regulation | <0,5% |
