Non-contact voltage and cable detector; LCD,bargraph
Kordarv:
1.0
Minimum quantity:
1.0
Tootekood:
AX-T2090
Tootja: AXIOMET
Tootja tootekood: AX-T2090
Product downloads
- pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABC2AD97901E80D6&compId=MEASURING.txt?ci_sign=d0ccb06ee923cc677e69012bfb5fb7bd92f37df8
- pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3945939C7126B&compId=INSTR-AX-T2090%20-%20EN.pdf?ci_sign=90143aa795d950e99524677043618ea8f375f484
- pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3ABEB707E25CAE1DC&compId=INB-TEST-EN.pdf?ci_sign=aaaf551ab9b544baa66bd2816fe4578821c3f28c
- pVersion=0046&contRep=ZT&docId=005056AB752F1ED3AD9ACE93B04901EC&compId=WARUNKI%20GWARANCJI%20EN_24.pdf?ci_sign=215d3a196f705e97f7384cba35c1cd8a395ebf55
- pVersion=0046&contRep=ZT&docId=005056AB752F1ED3AD9AD02EE60081EC&compId=WARUNKI%20GWARANCJI%20EN_24.pdf?ci_sign=117726e43e1636a9ec07071ec9a9213a4576a6b2
- pVersion=0046&contRep=ZT&docId=005056AB752F1EE4AF80771E46A72469&compId=warunki%20gwarancji_12_EN.pdf?ci_sign=3f7ac99182b9231616a273f0858a9d9898996e53
Spetsifikatsioon tootele Non-contact voltage and cable detector; LCD,bargraph
| Operating temperature | 0...40°C |
| Kind of display used | LCD |
| Output signal | 125kHz |
| Conform to the norm | CAT III 300V, EN 61010 |
| Receiver dimensions | 192x61x37mm |
| Transmitter dimensions | 130x69x32mm |
| Measuring instrument features | automatic power-off, detects cables in walls, detects discontinuities and short circuits in cables, set consisting of transmitter and receiver |
| Standard equipment | crocodile clips, hard case, test leads Heavy Duty, test probes |
| Type of tester | non-contact voltage and cable detector |
| Detection | voltage at depth up to 40cm, conductors at depth up to 0,5m (2-pole application), conductors at depth up to 2m (1-pole application) |
| Pollution degree | 2 |
| Detected voltage range | 12...400V AC |
