AC/DC digital clamp meter; I DC: 1000A; I AC: 3000A; VDC: 1000V
Multiples:
1.0
Minimum quantity:
1.0
Product code:
WMGBCMP3000
Manufacturer: SONEL
Manufacturer code: WMGBCMP3000
Product downloads
Specification for AC/DC digital clamp meter; I DC: 1000A; I AC: 3000A; VDC: 1000V
| IP rating | IP40 |
| Interface | Bluetooth |
| Temperature measuring range | -100...1000°C |
| Kind of display used | LCD |
| Conform to the norm | CAT III 1000V, EN 61010 |
| Measuring instrument features | automatic power-off, built-in torch, contactless voltage detector, HOLD function, InRush function, low battery indicator, MIN/MAX/REL function, PEAK HOLD function |
| Standard equipment | calibration certificate, drop-like K-type temperature probe, hard case, test leads |
| Measurement | AC current, AC voltage, capacitance, DC current, DC voltage, frequency, inrush current, resistance, temperature |
| Continuity test | acoustic indication, optical indication |
| Diode test | yes |
| True effective value measurement | True RMS AC+DC |
| Kind of meter | digital |
