Logger; 18÷265VAC; 22÷350VDC; on panel,panel; Temp: 0÷50°C; AR200

    Multiples: 1.0
    Minimum quantity: 1.0
    Product code: AR200.B/P/P/WA
    Manufacturer: APAR
    Manufacturer code: AR200.B/P/P/WA
    • Mounting
    • Mounting
    • Operating temperature
    • IP rating
    • IP rating
    • Type of module
    • Body dimensions
    • Temperature measuring range
    • Temperature measuring range
    • Additional functions
    • Additional functions
    • Additional functions
    • Additional functions
    • Additional functions
    • Additional functions
    • Communication with PC
    • Communication with PC
    • Power supply
    • Kind of input 1
    • Kind of input 1
    • Kind of input 1
    • Kind of input 1
    • Kind of input 1
    • Kind of temperature sensor
    • Kind of temperature sensor
    • Kind of temperature sensor
    • Kind of temperature sensor
    • Kind of temperature sensor
    • Kind of temperature sensor
    • Kind of temperature sensor
    • Kind of temperature sensor
    • Kind of temperature sensor
    • Kind of temperature sensor
    • Kind of temperature sensor
    • Kind of temperature sensor
    • Controlled parameter
    • Kind of output 1
    • The programming method
    • The programming method
    • The programming method
    • Kind of input 2
    • Kind of input 2
    • Kind of output 2
    • Kind of output 3
    • Input 1 properties
    • Input 1 properties
    • Input 1 properties
    • Regulation for output 1
    • Regulation for output 1
    • Regulation for output 2

    0.00 € 0.00 € (wo VAT) 0.0 EUR

    0.00 €

    This combination does not exist.

    Add to Cart

    Specification for Logger; 18÷265VAC; 22÷350VDC; on panel,panel; Temp: 0÷50°C; AR200

    Mounting on panel, panel
    Operating temperature 0...50°C
    IP rating IP20 at terminal side, IP54 (from the front)
    Type of module logger
    Body dimensions 96x48x79mm
    Temperature measuring range -200...850°C, -40...1200°C
    Additional functions 4MB of data memory, display brightness adjustment, error messages on the LED display, MODBUS RTU, OLED display, temperature compensation of thermocouple cold ends
    Communication with PC RJ45 Ethernet, USB
    Power supply external
    Kind of input 1 0...2,5kΩ, 0...10V, 0...60mV, 0/4...20mA, universal
    Kind of temperature sensor Ni100, Pt100, Pt500, Pt1000, thermocouple B, thermocouple E, thermocouple J, thermocouple K, thermocouple N, thermocouple R, thermocouple S, thermocouple T
    Controlled parameter temperature
    Kind of output 1 SPDT
    The programming method foil keypad, RS485, USB
    Kind of input 2 0...10V, 0/4...20mA
    Kind of output 2 SPST-NO
    Kind of output 3 0/4...20mA
    Input 1 properties current analog, RTD, thermocouple
    Regulation for output 1 ON-OFF with hysteresis, PID
    Regulation for output 2 ON-OFF with hysteresis
