Generator: arbitrary, function; Band: ≤40MHz; Channels: 2
Kordarv:
1.0
Minimum quantity:
1.0
Tootekood:
T3AFG40
Tootja: TELEDYNE LECROY
Tootja tootekood: T3AFG40
Product downloads
- pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABC2AD97901E80D6&compId=MEASURING.txt?ci_sign=d0ccb06ee923cc677e69012bfb5fb7bd92f37df8
- pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3ABEB6AD1B21981DC&compId=INB-GEN-EN.pdf?ci_sign=f58e04631ac85fd1fdfe92a8a0a1ca07e8f62e53
- pVersion=0046&contRep=ZT&docId=005056AB82531EE98D8863E673DAD8BF&compId=T3AFG40-80-120%20Data%20Sheet.pdf?ci_sign=b32310b83c327804f3858f50bf24750de6dc21c6
Spetsifikatsioon tootele Generator: arbitrary, function; Band: ≤40MHz; Channels: 2
| Supply voltage | 100...240V AC |
| Number of channels | 2 |
| Interface | LAN, USB |
| Dimensions | 260.3x107.2x295.7mm |
| Kind of display used | color, LCD 4,3" |
| Kind of modulation | AM, ASK, DSB-AM, FM, FSK, PM, PSK, PWM |
| Type of generator | arbitrary, function |
| Standard equipment | BNC cable, mains cable, USB cable, manufacturer's calibration certificate |
| Output parameters | impedance: 50Ω |
| Sampling | 1,2Gsps |
| Vertical resolution | 16bit |
| Waveform frequency range | 1µHz...25MHz (pulse waveform), 1µHz...25MHz (rectangular waveform) |
| Waveforms | arbitrary, impulse, noise, rectangular, sinus, triangle |
| Sweep mode | period: 1m...500s |
