Power supply: switched-mode; 120W; 24VDC; 24÷28VDC; 5A; 88÷264VAC
Kordarv:
1.0
Minimum quantity:
1.0
Tootekood:
SDR-120-24
Tootja: MEAN WELL
Tootja tootekood: SDR-120-24
Product downloads
- pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3ABEB71502DFCC1DC&compId=INB-ZAS-DIN-EN.pdf?ci_sign=4f05ad7e6bee992fce562e9c2b0560fdc0cebdad
- pVersion=0046&contRep=ZT&docId=005056AB752F1EE69E990BD1387EAFA8&compId=Short_Form_din.pdf?ci_sign=4a2af7d7cff1d8d967fcaabc249b97f9dbe19d22
- pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA390A2BDE3BA60C7&compId=Mean_Well_Industrial-Catalog.pdf?ci_sign=e5a3bf0d98e6bb6b792c315b1e2cf501830c330c
- pVersion=0046&contRep=ZT&docId=E1CFF23DFAB10EF1A704005056AB0C4F&compId=SDR-120-spec.pdf?ci_sign=1d72a876232cab580b85fe9a9b8a42fd4e3a1495
Spetsifikatsioon tootele Power supply: switched-mode; 120W; 24VDC; 24÷28VDC; 5A; 88÷264VAC
| Output current | 5A |
| Mounting | for DIN rail mounting |
| Supply voltage | 88...264V AC, 124...370V DC |
| Operating temperature | -25...70°C |
| Protection | overheating, anti-overload, anti-overvoltage, short circuit protection |
| Type of power supply | switched-mode |
| Series | SDR-120 |
| Body dimensions | 40x125.2x113.5mm |
| Output voltage | 24V DC |
| Additional functions | active PFC, output voltage correctness indication (NO contact) |
| Efficiency | 91% |
| Number of outputs | 1 |
| Electrical connection | terminal block |
| Kind of power supply | for DIN rail |
| Kind of case | 992A |
