Relay: electromagnetic; SPST-NC; Ucoil: 12VDC; Icontacts max: 30A

    Kordarv: 1.0
    Minimum quantity: 1.0
    Tootekood: S12-QAS-12
    Tootja: SHORI ELECTRIC
    Tootja tootekood: S12-QAS-12
    • Mounting
    • Operating temperature
    • Leads
    • Leads
    • Contact material
    • Body dimensions
    • Mechanical durability
    • Electrical life
    • Coil resistance
    • Rated coil voltage
    • Contacts configuration
    • Contact resistance
    • Contact current max.
    • Relay variant
    • Type of relay
    • Coil power consumption
    • Relay series
    • Operate time
    • Release time
    • Coil current

    2,34 € 2,34 € (KM-TA) 2.34 EUR

    2,34 €

    Seda kombinatsiooni ei eksisteeri.

    Lisa ostukorvi

    Product downloads

    Spetsifikatsioon tootele Relay: electromagnetic; SPST-NC; Ucoil: 12VDC; Icontacts max: 30A

    Mounting PCB
    Operating temperature -30...85°C
    Leads quick connect terminal, terminal PCB
    Contact material silver alloy
    Body dimensions 27.1x28.8x32mm
    Mechanical durability 10000000cycles
    Electrical life 10000cycles
    Coil resistance 155Ω
    Rated coil voltage 12V DC
    Contacts configuration SPST-NO
    Contact resistance 50mΩ
    Contact current max. 30A
    Relay variant power
    Type of relay electromagnetic
    Coil power consumption 930mW
    Relay series S12
    Operate time 15ms
    Release time 10ms
    Coil current 77mA
