Timer; 0,1s÷10min; SPDT; 250VAC/3A; 24VAC; DIN,socket,on panel
Kordarv:
1.0
Minimum quantity:
1.0
Tootekood:
H3RN-1 24VAC
Tootja: OMRON
Tootja tootekood: H3RN-1 24VAC
Product downloads
- pVersion=0046&contRep=ZT&docId=005056AB281E1EDFB7C63152C1ED80DC&compId=H3RN-1-24VAC-LNK.txt?ci_sign=91f33ddc851d26eb4cd3c41080ae19db134a1f68
- pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3ABEB6EE2712621DC&compId=INB-PRZEK-CZAS-EN.pdf?ci_sign=eac099eefad4e622c41d0c5e2b01403eca52005e
- pVersion=0046&contRep=ZT&docId=E1C04D47B81B88F1A6F5005056AB5A8F&compId=h3rn.pdf?ci_sign=cb29f62c34de35163624416bf78deb8570fd04da
Spetsifikatsioon tootele Timer; 0,1s÷10min; SPDT; 250VAC/3A; 24VAC; DIN,socket,on panel
| Mounting | socket |
| Supply voltage | 24V AC |
| Operating temperature | -10...55°C |
| IP rating | IP20 |
| Number of pins | 5 |
| Type of module | timer |
| Body dimensions | 31.2x12.8x47.4mm |
| Kind of output | SPDT |
| Indication | LED |
| Electrical connection | 4,75x0,5mm terminals |
| Counting range | 0,1s...10min |
| Counter operation modes | delayed switching on, ON for the set interval, symmetrical cyclical operation pause first, symmetrical cyclical operation pulse first |
| number of operation modes | 4 |
