Display: LCD; alphanumeric; STN Negative; 40x2; blue; 182x33.5mm
Kordarv:
1.0
Minimum quantity:
1.0
Tootekood:
EA W402-NLED
Tootja: ELECTRONIC ASSEMBLY
Tootja tootekood: EA W402-NLED
Product downloads
- pVersion=0046&contRep=ZT&docId=005056AB281E1EDCB7991B24E05AE0D2&compId=EA%20W402-NLED.pdf?ci_sign=179a4a562c31df99d71383ef1e841335e231795e
- pVersion=0046&contRep=ZT&docId=005056AB281E1EDE80A1B5BCC66760D5&compId=displays.txt?ci_sign=eaf78fd912bebb1d94d1d350f52cc04fb0aa44fb
- pVersion=0046&contRep=ZT&docId=005056AB90B41EDB8AAF6A40EB05A0C7&compId=display-visions.txt?ci_sign=bb0d6a37612ec70fbd412e3f6c33742a0c45459e
Spetsifikatsioon tootele Display: LCD; alphanumeric; STN Negative; 40x2; blue; 182x33.5mm
| Supply voltage | 4.5...5.5V DC |
| Contacts pitch | 2.54mm |
| Interface | 8bit BUS |
| Number of pins | 16 |
| Dimensions | 182x33.5mm |
| Type of pin configuration | 2x8 |
| Number of characters (columns x lines) | 40x2 |
| Kind of display | alphanumeric |
| Display technology | STN Negative |
| Backgr. colour | green |
| Backlight colour | white |
| Illumination | LED |
| Window dimensions (H x W) | 154.4x16.5mm |
| Kind of controller | HD44780 |
| Type of display | LCD |
| Digit height | 5.55mm |
| Character width | 3.2mm |
