Switch: emergency stop; Stabl.pos: 2; NC x2; 22mm; red; IP65; Pos: 2
Multiples:
1.0
Minimum quantity:
1.0
Product code:
YW1B-V4E02R
Manufacturer: IDEC
Manufacturer code: YW1B-V4E02R
Product downloads
- pVersion=0046&contRep=ZT&docId=005056AB281E1EDEBDE2A1EBFD78C0D6&compId=YW-Series.pdf?ci_sign=049236f39545a794e41a0ddb0a87e33eae4fb031
- pVersion=0046&contRep=ZT&docId=005056AB752F1EE894D44BA55C5B93D5&compId=XA_Series_EN.pdf?ci_sign=d419a5547f3e874d9994dcb3a78899cbafe4b719
- pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EC565DFF7E260C4&compId=IDEC-safety-switches-EN.pdf?ci_sign=a30cae3e283a572f6aa03645f23113b2d2f7700f
Specification for Switch: emergency stop; Stabl.pos: 2; NC x2; 22mm; red; IP65; Pos: 2
| Operating temperature | -25...55°C |
| IP rating | IP65 |
| Type of switch | emergency stop |
| Switches features | return by pulling, return by rotating |
| Number of positions | 2 |
| Mounting hole diameter | Ø22mm |
| Face dimensions | Ø40mm |
| Contacts configuration | NC x2 |
| Stable positions number | 2, bistable |
| Actuator colour | red |
| Button shape | mushroom |
| Button marking | arrows |
