Timer; 0,05s÷100h; DPDT; 250VAC/8A; 12÷240VAC; 12÷240VDC; DIN; IP40
Multiples:
1.0
Minimum quantity:
1.0
Product code:
TR-EM2P-UNI
Manufacturer: RELPOL
Manufacturer code: TR-EM2P-UNI
Product downloads
Specification for Timer; 0,05s÷100h; DPDT; 250VAC/8A; 12÷240VAC; 12÷240VDC; DIN; IP40
| Mounting | for DIN rail mounting |
| Supply voltage | 12...240V AC, 12...240V DC |
| Operating temperature | -25...55°C |
| IP rating | IP40 |
| Number of pins | 9 |
| Type of module | timer |
| Body dimensions | 87x35x60mm |
| Kind of output | DPDT |
| Indication | LED |
| Electrical connection | screw terminals |
| Counting range | 0,05s...100h |
| Counter operation modes | delayed switching off, delayed switching on, ON for the set interval, symmetrical cyclical operation pause first, with the control contact S |
| number of operation modes | 7 |
| OEM number | 2613057 |
| The additional control inputs | START |
