AC/DC digital clamp meter; Øcable: 48mm; I DC: 0,15÷1500A; 600g
Multiples:
1.0
Minimum quantity:
1.0
Product code:
F407
Manufacturer: CHAUVIN ARNOUX
Manufacturer code: F407
Product downloads
- pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABC2AD97901E80D6&compId=MEASURING.txt?ci_sign=d0ccb06ee923cc677e69012bfb5fb7bd92f37df8
- pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3ABEB6D412F7421DC&compId=INB-MIER-EN.pdf?ci_sign=9f97fafdfd0fa92910eac1938c04e02cb683e79f
- pVersion=0046&contRep=ZT&docId=005056AB752F1ED7AEC950FEED686A14&compId=CA-F407_M.PDF?ci_sign=e8222f1b22254705b4c1139f0bb821b50876eb62
- pVersion=0046&contRep=ZT&docId=005056AB752F1ED7AEC95BB88F3E6A14&compId=CA-F407_607_DS.PDF?ci_sign=5471d2c5ce3179535b6533f6220036b1ca8333fe
Specification for AC/DC digital clamp meter; Øcable: 48mm; I DC: 0,15÷1500A; 600g
| Interface | Bluetooth |
| Dimensions | 92x272x41mm |
| Kind of display used | LCD |
| Conform to the norm | CAT III 1000V, EN 61010 |
| Measuring instrument features | automatic power-off, harmonics analyser, low battery indicator, MIN/MAX function, PEAK function, selection of AC or AC+DC measurement, True InRush function |
| Standard equipment | 2 crocodile clips, case, test leads, test probes |
| Max. diameter of measured cable | 48mm |
| Measurement | AC current, AC voltage, active power, apparent power, continuity, DC current, DC voltage, frequency, harmonics, inrush current, reactive power, resistance |
| Continuity test | acoustic indication |
| True effective value measurement | True RMS |
| Kind of meter | digital |
